Anderson-Vortech Stage I Ti-Trim Supercharger Kit Passenger Side Mount. Fits 94-95 5.0L Mustang

Anderson / Vortech Stage I (V2) Ti-Trim Kit Supercharger Kit passenger side mount for 94-95 Mustang 5.0
Includes:
• 3.33 Upper Pulley, 6.87 Lower 8-Rib Pulley (10lb-12lb @ 6500 rpm)

(3.12 upper pulley also included for boost levels around 12-14lbs @ 6500 rpm)

• AFM Power By-Pass Kit
All mandrel bent construction, is the highest flowing inlet pipe available for centrifugal superchargers. It also puts the mass air in the inner fenderwell for a cooler intake charge.
Mounts the Mondo Bypass to a higher volume discharge tube for the higher boost levels of the Ti-Trim kit.  Ti is a "race" supercharger, no warranty expressed or implied. This is the only Mondo fitted kit for a 94-95 Mustang on the market. Comes with Mondo by-pass specific flange and proper hoses and clamps to complete the assembly.

• Vortech Mondo By-Pass Valve

• All Required Mounting Hardware by Vortech
• (No Fuel System, MAF, Air Filter or Tuning components included) Consult with your tuner for proper fuel and MAF suggestions.

Now Optional Moates Quarterhorse "Tuner" Package! Includes what is needed to tune one vehicle (tune not included). Select above.

Installation note*

If installing on a 94-95 Cobra there will be a few differences in the install process. The factory oil cooler you can keep or remove, however if you do keep you will need to pick up some flexible heater hose and reroute the cooler lines along with removing the metal coolant tube to install.

For all 94-95 vehicles you will need to vent the crankcase pressure to avoid blowing out seals on your engine. The easiest way will be to put a breather cap on your passenger side valve cover. Part number AF-26-1522 is what you will need.

Factory air conditioning lines will need to be bent to add clearance for by-pass and supercharger belt.

Due to popularity and different finish options lead times can vary on shipment, please see the "important order info" tab on the website for more details. This particular kit is a low volume product and on a "made to order" basis. Expect minimum 4-6 weeks for turn around.
