Anderson Power Pipe®. Fits 05-09 Mustang with Novi 2200 or Vortech Supercharger

Power Pipe® for 05-09 Mustang with Vortech/Paxton Novi 2200 Kit (requires tuning)

Select Head Unit Inlet Size Above

The AF-0134c Power Pipe® is designed for 05-09 Mustang GT equipped with Paxton Novi 2000 or Vortech JT-Trim super chargers with the front mount air to air intercooler (utilizing a blow through meter). The Power Pipe® flow an excess of 1300 CFMs, with pulling a cooler intake charge out of a custom 819 cubic inch air box. With this improved air flow and cooler intake charge. We have seen as much as 3lb of boost increase using the AF-0134c Power Pipe.

Designed for front mount intercooled systems, however can be used on a standard system but would need to run by-pass and line back into the 90 degree rubber elbow at the supercharger inlet for discharged air recirculation. Also would need a MAF at the end of the pipe instead of just a filter (not included).  Reference Video for installation tips.

What's Included:

Heat Shield

Pipe Assembly

Air Filter

90 Degree Coupler & Clamps

Passenger Side Breather Filter

*For draw-thru systems a shorter air filter is included and a short joiner coupler with clamps to allow for use with MAF housing (MAF Housing Sold Separately, consult with your tuner for recommended housing)

Installation note* Your Vortech or Paxton kit will include a valve cover breather hose you may run back to the pipe inlet or use the included filter breather - installers preference

Using the Power Pipe® with DBX85 mass air combination with a smaller pulley AFM
has made 630 rwhp with a Novi 2200 Tested back to back Vortech Intake compared to Anderson AF-0134c Power pipe
WOW 56 Rear Wheel Horse Power and 30 ft.lb of Torque

Run 14. 2006 Mustang Gt., 5 speed,4.10 r&p, PER 5.0L 9.25 cr engine,comp cams, PER ported heads, DBX mass air meter, 60 lb injectors, GT 500 fuel pumps, Vortech YSI 2.5" pulley,Vortech air/air intercooler,10% overdrive damper, Standard Vortech intake pipe 18 degrees of timing made 22 lb of boost

Run 15. same as Run 14 except Anderson Power Pipe®. Boost  jumped up to 27lb . Timing still at 18 degrees
