Anderson - MF Kustoms Holley Terminator X Kit 1996-1998 Mustang GT/Cobra

For 96-98 Mustang GT/Cobra with Manual Transmission and modular 4.6L engine

Cut down and simplify your installation with the NEW Anderson - MF Kustoms Holley Terminator X kit for the modular 96-98 Mustang!

AT LAST!!! A Terminator X kit designed for the 96-98 modular Mustang is here! Anderson Ford Motorsport has partnered with MF Kustoms to create a Terminator X kit that not only simplifies the installation process but also cuts down your labor time by nearly 80%! The key is the MF Kustoms plug & play adapter that plugs the Holley Terminator X into the factory EEC connector in the kick panel. This feature alone saves you a ton of labor on your installation. Not only that, the included adapter harness allows you to plug the included Bosch 4.9 wideband sensor to be used in the system. This system allows you to keep your factory wiring harness in tact and allows you to return everything back to factory if you so desired. The system is already pinned out properly for use with the factory Ford IAC motor and factory air conditioning. No messing with the CCRM or PATS is required, no external coil drivers required! Another excellent feature is the dual CAN connections built into the harness to allow use for a 3.5" touchscreen handheld (additional option), digitial dash, and CAN-USB adapter (included) without needing an additional CAN splitter harness. All Holley Terminator X functionality remains the same tuning wise via the software and handheld (if purchased). Software and firmware updates are all available through Holley's website. This kit is the perfect solution if you have a great condition factory wiring harness.

This kit comes with everything you need to install into your 1996-1998 Mustang with the Modular Ford 4.6L engine.

Note*

96-98 4V Cobra's will be required to delete the IMRC's.

Sub harness has the following connectors:

• Fuel Pressure
• Oil Pressure
• Manifold Air Pressure
• Flex Fuel

Not CARB certified or EO compliant, for Off-Road use ONLY

Holley Terminator X ECU

MF Kustoms Plug&Play Adapter

MF Kustoms Wiring Harness

Bosch 4.9 Wideband Sensor

Power Harness

CAN-USB Laptop Tuning Cable

Optional:

3.5" Touchscreen Handheld

(System is setup to use the internal 1 bar MAP sensor for naturally aspirated combinations, however there is a terminated plug for use with external MAP sensors)

Shipping Note*

Due to low volume of order frequency for this kit we have moved these to a "made to order" basis. Please expect 1-2 weeks for shipment (possibly sooner) unless there is any back ordered components.

Warranty Notice* Holley warranty is for the main ECU only. Holley ECU's are granted a 90 day warranty from time of order. We recommend not purchasing a kit unless you plan on installing it within 30 days of receipt to be within the warranty period. AFM has no control over Holley warranty policy. Widebands and other components in the kits have no warranty.
